If the ink inside the cartridge is under the lowest warning line, please stop printing and refill the ink tank.
- Open the small cap of the ink bottle
- Open the ink cartridge cover, align the ink bottle mouth with the ink inlet. The ink fill should be between the lowest and the highest scales
- Pull out the ink bottle after filling and close the ink cartridge cover, ink cover and printer top cover
- Refill the ink if it is below the minimum level
- Keep the product in a cool place away from the sunlight
- Use the product within the service period to ensure optimum print quality. This product should be used at a temperature between 5 and 35 degrees
- If ink gets into your eyes, flush immediately with large amounts of water. If the ink leaks into your skin, wipe it off with a tissue. Keep the product away from children
Problem: Colour mixing
The prints are coming out with blended colours.
Resolution
- Please check if the ink colour in the ink tank is consistent with the printer’s ink tank marked
Problem: White line
The prints are coming out with a white line.
Resolution
- Run the cleaning operation up to three times
Problem: Broken line
The prints are coming out with a broken line
Resolution
- Check if the paper tray is flat and if the printer needs maintenance
|
This image shows the front of the cartridge, the product range and colour is displayed on the large label.
|
|
|
|
The back of the cartridge can be seen in this image, the chip must be clear of impurities before installation.
|
|
|
|
This image shows the left side of the cartridge.
|
|
|
|
The right side of the cartridge can be seen in this image, the orange clip must be removed before installation.
|
|
|
Printers that use Canon GI-56 cartridges
To see a full list of products that work in your printer, click on the model name below:
All trademarks, photos and logos included on this information sheet are the property of their respective owners.
