Compatible HP 56 & 57 (C6656AN-RET, C6657AN-RET)

  • Updated

Product_Information.jpg Cartridge_Images_Title.jpg

Compatible HP 56 & 57 (Top View)
Compatible HP 56 & 57 (Bottom View)



Compatible HP 56 & 57
(Side View)
Compatible HP 56 & 57
(Side View Without Clips)



Compatible HP 56 & 57
(Back + Chip View)







Problem: Error (Circuit Error)

The error message (Circuit Error) intermittently appears when the cartridge is installed

Resolution

  • Remove the black cartridge then the colour cartridge
  • Reinstall the black cartridge then the colour cartridge
  • This error should disappear




Problem: Printing top/ bottom half of words

The cartridge is not printing the bottom/ top half of words



Problem: Printing blank pages / Fading on print / Incorrect colours being produced

Printouts are coming out very faded or blank, or with the incorrect colours.

Resolution

In the unlikely event that your cartridge is not printing to your satisfaction, there may be a blockage on the print nozzles caused either by dried ink particles or an air lock.

This problem can easily be remedied by carrying out a simple manual cleaning procedure:

  • 1. Take a cotton bud and dampen with some warm water. Then gently wipe around the area of the print head at the base of the cartridge.
  • 2. Afterwards, dab the print head onto a clean absorbent paper kitchen towel until the ink begins to filter through. The following colours should be visible on the kitchen towel:
For the black cartridge - a full black oval shape
For the colour cartridge - 3 distinct oval or round shapes should be seen coloured cyan, magenta and yellow
  • 3. Take a clean, dry paper kitchen towel and gently wipe the copper contact points at the back of the cartridge and the contacts inside the printer cartridge carrier.





Printers that use HP 56 & 57 cartridges

All trademarks, photos and logos included on this information sheet are the property of their respective owners.
