GX6050

Ink Tank Refill Instructions

If the ink level is below the lowest warning line, stop printing and refill the ink tank.
Open the small cap of the ink bottle.
Open the ink cartridge cover and align the ink bottle nozzle with the ink inlet. Fill the ink between the minimum and maximum level indicators.
Remove the ink bottle after filling, then close the ink cartridge cover, ink cap, and printer top cover.
Refill the ink whenever it falls below the minimum level.
Store the product in a cool place away from direct sunlight.
Use the product within its service period for best print quality. Recommended operating temperature is between 5°C and 35°C.
If ink gets into your eyes, rinse immediately with plenty of water. If it comes into contact with skin, wipe it off with a tissue.
Keep the product out of reach of children.

Ink in the cartridge, but not printing

The cartridge may show as empty or produce faded print despite ink remaining.
Printing stops once the cartridge reaches around 30% remaining ink, which is kept as a reserve.
This reserve cannot be accessed and is used to keep the internal sponge moist and protect the printhead.
This is normal behaviour and not a fault.
The cartridge will need to be replaced.

Colour mixing

Check that the ink colour in the ink tank matches the printer’s labelled ink tank.

White line

Broken line
