MFC-L8390CDW

Printer cartridge installation
Printer cartridge installation
Replace Toner / Toner Low / No Toner Installed
    With Brother consumables, you have to manually reset the counter to let the machine know an item has been replaced.
  • Make sure the machine is turned on.
  • Make sure the machine's cover is open
  • Press X to go to the home page
  • Press and hold Toner and then press and hold Drum until the "Reman" menu appears, this is the menu to reset the toner count.
  • Press Down to find the toner that you have replaced and press the colour you want to reset.
  • Press Yes
  • When the printer shows Accepted on the screen, the count is now reset and the printer should be ready to use
Printer cartridge installation
Replace Drum / Drum End / No Drum Installed
    With Brother consumables, you have to manually reset the counter to let the machine know an item has been replaced.
  • Make sure the machine is turned on.
  • Make sure the machine's cover is closed.
  • Press and hold Toner for about five seconds.
  • Press Drum
  • Select the toner colour for the drum unit you just replaced. and then press OK.
  • Press Yes key to reset the drum counter.
Printer cartridge installation
My prints are faded
  • If the print quality is poor, remove the toner cartridge from the printer and gently rock it side to side.
  • This movement helps distribute the toner evenly within the cartridge.
  • After rocking the cartridge 5–6 times, reinsert it and print a test page.
  • If the issue persists, check the life of maintenance items in case they need replacing
Printer cartridge installation
Printer cartridge installation

Printers that use Brother TN-248 / TN-248XL cartridges

To see a full list of products that work in your printer, click on the model name below:

DCP-L3515CDW DCP-L3527CDW HL-L3215CW HL-L3240CDW
MFC-L3740CDW MFC-L8340CDW DCP-L3520CDW DCP-L3555CDW
HL-L3220CW HL-L8230CDW MFC-L3740CDWE MFC-L8390CDW
DCP-L3520CDWE DCP-L3560CDW HL-L3220CWE HL-L8240CDW
MFC-L3760CDW

Printers that use Brother TN-249 cartridges

Click on your printer model below to view all compatible TN-249 products:

HL-L8230CDW HL-L8240CDW
MFC-L8340CDW MFC-L8390CDW

Printer Consumables

TN-248BK TN-248C TN-248M TN-248Y
TN248VAL TN-248XLBK TN-248XLC TN-248XLM
TN-248XLY TN-248XL-PACK DR248CL WT229CL
TN-248XLBK-REM TN-248XLC-REM TN-248XLM-REM TN-248XLY-REM
TN-248XL-PACK-REM TN-248BK-REM TN-248C-REM TN-248M-REM
TN-248Y-REM TN248VAL-REM
