HL-2250(DN)
Replace Toner / Toner Low / No Toner Installed
Replace Drum / Drum End / No Drum Installed
My prints are faded
- If the print quality is poor, remove the toner cartridge from the printer and gently rock it side to side.
- This movement helps distribute the toner evenly within the cartridge.
- After rocking the cartridge 5–6 times, reinsert it and print a test page.
- If the issue persists, check the life of maintenance items in case they need replacing
My prints have marks on the page
Streaks/bands
-
The Corona Wires may need cleaning, to do this follow the steps below.
- Turn off the machine.
- Take out the drum unit and toner cartridge assembly and place on a clean flat surface with a sheet of disposable paper underneath in case toner is accidentally spilt.
- Clean the primary corona wire inside the drum unit by gently sliding the green tab from left to right and right to left several times.
- Return the tab to the home position so that the ^ images match up if not the pages printed may have a vertical stripe.
- Return the cartridge to the printer, repeat for all other remaining cartridges.
- Close the printer and turn this back on. This should now be ready to use.
Printers that use Brother TN-2210 / TN-2220 cartridges
To see a full list of products that work in your printer, click on the model name below:
| HL-2250DN | MFC-7360N | MFC-7460DN |
| Fax-2840 | MFC-7860DW | DCP-7065DN |
| DCP-7060D | DCP-7070DW | Fax-2940 |
| MFC-7460N | Fax-2490 | HL-2240D |
| HL-2250 | HL-2270 |
Printer Consumables
| DR2200 | DR2200-REM | TN2210 | TN2210-REM |
| TN2220 | TN2220-REM |
